Portable type instruments are Electrodynamometer type instrument. They can be used in Single phase, Three phase Three wire and Three phase.

The wattmeter is an instrument for measuring the electric power (or the supply rate electrodynamometer type instruments pdf of electrical energy) in watts of any given circuit Kmsnano V15 Offline Office And Windows Kms Activator. ..electromagnetic wattmeters.

Electrodynamometer (Electrodynamics) Type. • Electrodynamometer types of instruments are used as a. Parasitologi Kedokteran Pdf Programs more. c. Voltmeters and ammeters both in the range of. Electrodynamometer type instruments pdf Great idea, El efecto isaias gregg braden.pdf, Lyman 49th edition reloading handbook pdf. Portable type instruments are Electrodynamometer type instrument. They can be used in Single phase, Three phase Three wire and Three phase.

There are two general types of moving-iron instruments namely: • Repulsion (or double iron) type (figure 1) • Attraction (or single-iron) type (figure 2) The brief description of different components of a moving-iron instrument is given below: • Moving element: a small piece of soft iron in the form of a vane or rod. • Coil: to produce the magnetic field due to current flowing through it and also to magnetize the iron pieces. • In repulsion type, a fixed vane or rod is also used and magnetized with the same polarity. • Control torque is provided by spring or weight (gravity). • Damping torque is normally pneumatic, the damping device consisting of an air chamber and a moving vane attached to the instrument spindle. • Deflecting torque produces a movement on an aluminum pointer over a graduated scale.

How it works? The deflecting torque in any moving-iron instrument is due to forces on a small piece of magnetically ‘soft’ iron that is magnetized by a coil carrying the. In repulsion type moving–iron instrument consists of two cylindrical soft iron vanes mounted within a fixed current-carrying coil. Typical scheme of measuring el. Current and voltage One iron vane is held fixed to the coil frame and other is free to rotate, carrying with it the pointer shaft. Two irons lie in the magnetic field produced by the coil that consists of only few turns if the instrument is an ammeter or of many turns if the instrument is a voltmeter.

Current in the coil induces both vanes to become magnetized and repulsion between the similarly magnetized vanes produces a proportional rotation. The deflecting torque is proportional to the square of the current in the coil, making the instrument reading is a true ‘RMS’ quantity Rotation is opposed by a hairspring that produces the restoring torque. Only the fixed coil carries load current, and it is constructed so as to withstand high transient current. Moving iron instruments having scales that are nonlinear and somewhat crowded in the lower range of calibration.

Figure 1 – Repulsion moving iron-instrument Figure 2 – Attraction moving iron instrument Measurement of Electric Voltage and Current • Moving iron instruments are used as Voltmeter and Ammeter only. • Both can work on AC as well as on DC. Ammeter • Instrument used to measure current in the circuit. • Always connected in series with the circuit and carries the current to be measured. • This current flowing through the coil produces the desired deflecting torque. • It should have low resistance as it is to be connected in series. Voltmeter • Instrument used to measure voltage between two points in a circuit.

• Always connected in parallel. • Current flowing through the operating coil of the meter produces deflecting torque. • It should have high resistance. Thus a high resistance of order of kilo ohms is connected in series with the coil of the instrument. Ranges of Ammeter and Voltmeter • For a given moving-iron instrument the ampere-turns necessary to produce full-scale deflection are constant. • One can alter the range of ammeters by providing a shunt coil with the moving coil.
